Description
Monitoring of unbalance vibration to ISO 10816/ISO 20816
Monitoring of bearing vibration
Detection of particular vibration frequencies by FFT (M14)
Measuring ranges and filters adjustable
RMS and peak values
Inputs for IEPE transducers
USB and RS-485 interfaces for digital setup and measurement (M14)
Level indication at front side
Relay outputs with adjustable thresholds and delays
Isolated 4 .. 20 mA current loop
Wide-band output
Self-test functions
Teach-in for alarms (M14)
35 mm DIN rail attachment
