Temperatura de operare: -40° to +70°C (standard), -55° to +85°C (extinsa), Fara condens
Rate maxima achizitie 1000 Hz
Material carcasa Aluminiu anodizat
Intrari analogice 16 simple sau 8 diferentiale ( configurabile individual)
Numarator de pulsuri 10 (P1 la P2 si C1 la C8)
Iesiri de tensiune 4 (VX1 la VX4)
Curent maxim de alimentare ±40 mA ( excitatie), 50 mA (sursa fixa de 3.3 or 5 V)
Porturi de comunicatie - USB-C, Ethernet, RS-232, RS-485, RS-422, CS I/O, CPI;
Stocare date microSD
Switch 12V 2 terminale, plus CS I/O pin 8
Intrari -iesiri digitale I/O 8 terminale (C1 to C8) configurabile pentru intrari si iesiri digitale precunm si interfete seriale UART, RS-232, RS-485, SDM, SDI-12, I2C, si SPI, configurabile pentru 5 V or 3.3 V nivel logic.
Limita tensiune intrare ±5 V
Precizie Analog Voltage Accuracy
• ±(0.04% din masuratoare + offset) at 0° to 40°C
• ±(0.06% din masuratoare + offset) at -40° to +70°C
ADC 24-bit
Alimentare 10 - 36 V
Ceas de timp real - precizie ±3 min. pe an (±10 µs cu GPS)
Protocoale Internet Ethernet, PPP, RNDIS, ICMP/Ping, Auto-IP (APIPA), IPv4, IPv6, UDP, TCP, TLS (v1.2), DNS, DHCP, SLAAC, Telnet, HTTP(S), SFTP, FTP(S), POP3/TLS, NTP, SMTP/TLS, SNMPv3, CS I/O IP, MQTT(S)
Protocoale de comunicatie CPI, PakBus, SDM, SDI-12, Modbus, TCP, DNP3 outstation, UDP, NTCIP, NMEA 0183, I2C, SPI, CampbellCloud HTTPS/MQTTS, si altele;
Battery-Backed SRAM for CPU Usage and Final Storage 4 MB
Data Storage 4 MB SRAM + 72 MB flash (storage expansion of up to 16 GB with removable microSD flash memory card)
Idle Current Drain, Average < 2.0 mA (@ 12 Vdc)
Active Current Drain, Average
• 1.1 mA (1 Hz scan @ 24 Vdc)
• 2 mA (1 Hz scan @ 12 Vdc)
• 57 mA (20 Hz scan @ 12 Vdc)
Dimensiuni 23.8 x 10.1 x 6.2 cm
