Description
The compact, light weight and cost-effective spectrum analyzer 2650A is for quick and precise signal investigations, especially away from the bench. At a weight of only 4 pounds (1.8 kg), this instrument is by far the lightest full-featured handheld spectrum analyzer available, yet it deliver performance and features comparable to a full-size bench spectrum analyzers and can operate up to 4 hours on a single battery.
With its ease of use, measurement flexibility and unmatched portability, the 2650A is an indispensible tool for engineers and technicians who conduct field measurements in the 50 kHz to 3.3 GHz range.
Technical data
■ Frequency range from 50 kHz - 3.3 GHz
■ A truly portable spectrum analyzer weighing only 1.8 kg including the battery
■ Impressive 4 hour battery life; easy-to-replace rechargeable Lithium-Ion battery
■ USB interface for PC connectivity
■ Intuitive PC Software for remote control and documentation of measurement results
■ Conveniently store measurement results and screen shots in bitmap format to USB flash
drive (USB host interface)
■ Large easy-to-read color display (TFT LCD), 640 x 480 resolution
■ Measurement functions: channel/adjacent channel power, occupied bandwidth, electric
and magnetic field strength
■ Convenient Auto Tune function automatically sets center frequency to the maximum signal
within full span and optimum settings for RBW, VWB and sweep time
■ External trigger for zero span measurements
■ SCPI-like remote control commands
