Description
Ranges 50 - 4000 mm
Resolution max. 2 µm
Measured value position and speed with CANopen
Linearity max. ±0.02 %
Displacement speed < 10 m/s
Analog output 0 - 10 V, 4 - 20 mA
Digital output SSI, CANopen
Voltage supply 24 VDC ±20 %
Protection class
IP67 / max. 350 bar
Operating temperatur -30..+75 °C (-30 - 90 °C for SSI output)
Magnetic cursor magnetic cursor or floating cursor for liquids
