Sefram MW3360 & 3365 & 3390 & 3395 - 600/1500A AC/DC Clamp MetersMW3360, MW3365, MW3390, MW3395

Array
Download PDF

Description

  • 4000-count display, analogue bargraph
  • Current measurement up to 600A AC/DC (MW3360 & MW3395); 1500A AC/DC (MW3390 & MW3395)
  • Voltage measurement up to 600V AC/DC (MW3360 & MW3365); 750V AC & 1000V DC (MW3390 &MW3395)
  • TRMS AC (MW3365 & MW3395)
  • Resistance and Frequency measurement
  • Continuity test
  • Hold, Peak, Min and Max functions
  • Safety : IEC 1010, 600V CAT III



Back
CODAC / DC Current (A)Opening jaw (mm)AC / DC Voltage (V)TRMS AC
MW3360600 / 600max.45600 / 600no
MW3365600 / 600max. 45600 / 600yes
MW33901500 / 1500max. 53750 / 1000no
MW33951500 / 1500max. 53750 / 1000yes
